CONECTOR MACHO DIN ACODADO 21 PINES

Conector DIN macho acodado para circuito impreso 21 pines
Contact type: Male connector
Contact spacing: 2,5mm
Insulator: Standard insulator
Product Type: DIN 41617
Size/Number of positions: 21 pos
Termination signal contact: Solder pin angled
Insulator color: Grey
Insulator material: PC GF UL 94 V-1
Plating signal contact (mating area): Silver
Plating signal contact (termiation area): Tin plated
Signal contact material: Copper alloy
Current rating signal: 4A
Contact resistance standard: 15 mOhm
Extraction force: 48N
Insertion force: 48N
Insulation resistance: 10 GOhm
Mating cycles: 500
Max. working temperature: +125° C
Min. working temperature: -65° C

• Tipo: C.I.
• Conector: Din
• Pines: 21
• Versión: Macho
• Forma: Acodado
